Same model may have multiple batches, images only for reference.
KBU1004-G Real Image
Same model may have multiple batches, images only for reference.

KBU1004-G

Part No KBU1004-G
Manufacturer Comchip Technology
Catalog Bridge Rectifiers
Description RECT BRIDGE CELL 400V 10A KBU / Diode Rectifier Bridge Single 400V 10A 4-Pin Case KBU Box
Datasheet
KBU1004-G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Comchip Technology
Packaging Tray
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Maximum) 400V
Current - Average Rectified (Io) 10A
Voltage - Forward (Vf) (Maximum) @ If 1V @ 5A
Current - Reverse Leakage @ Vr 10μA @ 400V
Operating Temperature Range -55°C ~ 150°C (TJ)
Mounting Style Through Hole
Package 4-SIP, KBU
Manufacturer Package KBU
Win Source Part Number 777986-KBU1004-G
Popularity Medium
Supply and Demand Status Limited
Quantity per package 400
Family Name KBU1004
Introduction Date December 25, 2008
ECCN EAR99
Country of Origin Taiwan
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian KBU1004-G CAD Model

Description

The Comchip Technology KBU1004-G is a medium-popularity electronic component. The specifications are as follows:

  • Package: 4-SIP, KBU
  • Mounting Style: Through-hole
  • Operating Temperature Range: -55°C to 150°C (TJ)
  • Diode Type: Single Phase
  • Average Rectified Current (Io): 10A
  • Reverse Leakage Current @ Vr: 10μA @ 400V
  • Voltage Peak Reverse (maximum): 400V
  • Voltage Forward (Vf) (maximum) @ If: 1V @ 5A
  • Supply and Demand Status: Limited
  • Threat of Fake Products: 54%
  • Brand: Comchip Technology
