The XAL6030-102MEC is a shielded power inductor manufactured by Coilcraft. This inductor is designed for use in high-performance DC-DC converters and power supply applications. It provides high efficiency, low DC resistance, and excellent current handling capabilities. The shielded construction minimizes electromagnetic interference (EMI), making it suitable for sensitive electronic environments.

Applications

• DC-DC Converters: Commonly used in buck, boost, and buck-boost converters to store and release energy efficiently.
• Power Supplies: Integrated into power supplies for various electronic devices, including computers, servers, and industrial equipment.
• Voltage Regulators: Used in voltage regulator circuits to maintain a stable output voltage despite variations in input voltage or load current.
• Filtering Applications: Employed in LC filters to reduce noise and ripple in power lines and signal paths.
• LED Lighting: Utilized in LED driver circuits to provide efficient and stable current regulation.

Features

• Inductance: 1.0 µH (1.0 microhenry).
• Tolerance: Typically ±20%.
• Saturation Current: High saturation current rating allows the inductor to handle large peak currents without significant inductance drop.
• Shielded Construction: Minimizes EMI radiation, reducing interference with nearby components and circuits.
• Low DC Resistance (DCR): Very low DCR minimizes power losses, leading to improved efficiency.
• Operating Temperature: Wide operating temperature range, typically from -40°C to +125°C, suitable for harsh environments.
• Footprint: Compact 6.2 mm x 6.2 mm footprint for space-saving designs.

Benefits

• High Efficiency: Low DCR results in minimal power losses, maximizing the efficiency of the power conversion system.
• Reduced EMI: Shielded construction effectively reduces electromagnetic interference, ensuring stable and reliable operation.
• Compact Size: Small footprint allows for high-density circuit designs, saving valuable board space.
• Excellent Current Handling: High saturation current capability enables the inductor to handle high peak currents without performance degradation.
• Robust Performance: Designed for reliable operation in a wide range of environmental conditions, ensuring long-term stability.

The XAL6030-102MEC from Coilcraft is a high-quality inductor that provides excellent performance in demanding power applications. Its shielded construction, low DCR, and high current handling capabilities make it an ideal choice for DC-DC converters, power supplies, and voltage regulators. The inductor's compact size and wide operating temperature range further enhance its versatility. The XAL6030-102MEC is designed for automated assembly, facilitating efficient manufacturing processes.
