CMX7141Q3 Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer CML Microcircuits
Function Baseband Processor
RF Type General Purpose
Secondary Attributes 3V ~ 3.6V Supply
Manufacturer Package 48-VFQFN Exposed Pad
Supplier Device Package 48-VQFN (7x7)
Manufacturer Pack Quantity 1
MSL Level 3 (168 Hours)
Win Source Part Number 242749-CMX7141Q3
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian CMX7141Q3 CAD Model

Description

Product Overview

The CMX7141Q3 is a high-performance, quad-band digital radio IC offering exceptional integration for communication devices. It is designed to provide efficient, reliable operation in a compact form factor.

Applications and Projects

  • Portable two-way radios
  • Digital mobile radios
  • Wireless communication systems
  • Custom communication devices

Features and Benefits

  • Supports multiple frequency bands for broad compatibility
  • Integrated DSP for robust signal processing
  • Low power consumption enhancing battery life
  • High sensitivity for improved performance in challenging environments

The CMX7141Q3 integrates cutting-edge technology that simplifies development while maintaining optimal performance, making it ideal for modern communication applications.
