The 74HC86D is a high-speed Si-gate CMOS device that is pin compatible with low-power Schottky TTL (LSTTL). Manufactured by NXP, a trusted leader in the semiconductor industry, the 74HC86D is part of the 74HC family, which is renowned for its robustness and versatility.

Key Features

• Logic Type: EXCLUSIVE-OR Gate
• Number of Circuits: 4
• Inputs per Circuit: 2
• Supply Voltage Range: 2.0 to 6.0 V
• Output Current: ±5.2 mA
• Propagation Delay Time: 8 ns at 4.5 V, 10 ns at 6 V
• Operating Temperature: -40°C to +125°C
• Package Type: SOIC-14

Product Description

The 74HC86D, with its four independent 2-input Exclusive-OR gates, is designed to perform functionally the same operations as the equivalent bipolar Schottky logic component. This device allows for the implementation of exclusive logical functions, which is essential in digital circuits for parity generation and checking, as well as in arithmetic circuits and various coding and decoding applications.

Each gate of the 74HC86D is capable of operating over a wide voltage range from 2.0 to 6.0 volts, ensuring compatibility with a variety of logic families. Additionally, the low power consumption and balanced propagation delays make it a suitable choice for battery-operated devices, portable equipment, and other power-sensitive applications.

The device is offered in a small-outline 14-pin package, which is designed for optimized PCB space usage. The 74HC86D is characterized for operation from -40°C to +125°C, providing reliable performance across a wide range of environmental conditions.

Whether designing high-speed logic systems or looking for a reliable component for your digital application, the NXP 74HC86D offers a perfect blend of speed, power efficiency, and reliability.
