HSMS-2812-TR1 Broadcom Limited HSMS-2812-TR1 Real Image HSMS-2812-TR1 label picture HSMS-2812-TR1 real image 2
Same model may have multiple batches, images only for reference.
HSMS-2812-TR1 Broadcom Limited HSMS-2812-TR1 Real Image HSMS-2812-TR1 label picture HSMS-2812-TR1 real image 2
HSMS-2812-TR1 Broadcom Limited HSMS-2812-TR1 Real Image HSMS-2812-TR1 label picture HSMS-2812-TR1 real image 2
Same model may have multiple batches, images only for reference.

HSMS-2812-TR1

Part No HSMS-2812-TR1
Manufacturer Broadcom Limited
Catalog RF Diodes
Description Surface Mount RF Schottky Barrier Diodes | RF DIODE SCHOTTKY 20V SOT23-3
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Broadcom Limited
Packaging Tape and Reel
Status Obsolete
Diode Type Schottky - 1 Pair Series Connection
Voltage - Peak Reverse (Maximum) 20V
Current - Max 1A
Capacitance at Vr, F 1.2pF at 0V, 1MHz
Resistance at If, F 15Ohm at 5mA, 1MHz
Temperature Range - Operating 150°C
Manufacturer Package TO-236-3, SC-59, SOT-23-3
Supplier Device Package SOT-23-3
Family Part Number HSMS-2812
Manufacturer Pack Quantity 3,000
MSL Level 1 (Unlimited)
Win Source Part Number 1181929-HSMS-2812-TR1
Manufacturer Homepage www.home.agilent.com
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian HSMS-2812-TR1 CAD Model

Description

The HSMS-2812-TR1 is a Schottky diode pair from Broadcom Limited.

  • Product Name: HSMS-2812-TR1
  • Manufacturer: Broadcom Limited
  • Type: Schottky diode pair
  • Maximum Current Rating: 1A
  • Peak Reverse Voltage: 20V
  • Package: SOT-23-3
  • Status: Obsolete
  • Capacitance: 1.2pF @ 0V, 1MHz
  • Resistance: 15Ohm @ 5mA, 1MHz
  • Family: HSMS-2812
  • Manufacturer Pack Quantity: 3,000
  • MSL Level: 1 (Unlimited)
  • Applications: Discrete semiconductor products
