HCPL-4200-500E AVAGO TECHNOLOGIES LIMITED HCPL-4200-500E Real Image
Same model may have multiple batches, images only for reference.
HCPL-4200-500E AVAGO TECHNOLOGIES LIMITED HCPL-4200-500E Real Image
HCPL-4200-500E AVAGO TECHNOLOGIES LIMITED HCPL-4200-500E Real Image
Same model may have multiple batches, images only for reference.

HCPL-4200-500E

Part No HCPL-4200-500E
Manufacturer Broadcom Limited
Catalog Special Purpose
Description OPTOISO 3.75KV RECEIVER 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Isolators - Special Purpose Isolators
Mfr Broadcom Limited
Package Tape & Reel
Product Status Active
Type Current Loop Receiver
Number of Channels 1
Voltage - Isolation 3750Vrms
Common Mode Transient Immunity (Min) 1kV/µs
Input Type DC
Current - Output / Channel 25mA
Propagation Delay tpLH / tpHL (Max) 1.6µs, 1µs
Rise / Fall Time (Typ) 55ns, 15ns
Voltage - Supply 4.5V ~ 20V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 8-SMD, Gull Wing
Supplier Device Package 8-DIP Gull Wing
Approval Agency CSA, UR
Base Product Number HCPL-4200
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 745957-HCPL-4200-500E
Ultra Librarian 3D Model Ultra Librarian HCPL-4200-500E CAD Model

Description

The Broadcom Limited 745957-HCPL-4200-500E is a current loop receiver isolator designed for special purpose applications.

  • Category: Isolators - Special Purpose Isolators
  • Isolation: electrical isolation between input and output circuits
  • Voltage Isolation Rating: 3750Vrms
  • Channel: single
  • Current Output: 25mA
  • Propagation Delay (tpLH): 1.6μs
  • Propagation Delay (tpHL): 1μs
  • Mounting Type: surface mount
  • Package: 8-SMD gull wing
  • Operating Temperature Range: -40°C to 85°C
