HCPL-2231-000E Real Image HCPL-2231-000E real image4561 HCPL-2231-000E Real Image1 HCPL-2231-000E Real Image2 HCPL-2231-000E Real Image3
Same model may have multiple batches, images only for reference.
HCPL-2231-000E Real Image HCPL-2231-000E real image4561 HCPL-2231-000E Real Image1 HCPL-2231-000E Real Image2 HCPL-2231-000E Real Image3
HCPL-2231-000E Real Image HCPL-2231-000E real image4561 HCPL-2231-000E Real Image1 HCPL-2231-000E Real Image2 HCPL-2231-000E Real Image3
Same model may have multiple batches, images only for reference.

HCPL-2231-000E

Part No HCPL-2231-000E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description Optocoupler Logic-Out Totem-Pole DC-IN 2-CH 8-Pin PDIP Tube / OPTOISO 3.75KV 2CH PSH PULL 8DIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Tube/Rail
Status Active
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Isolation Voltage 3750Vrms
Common Mode Transient Immunity (Min) 1kV/μs
Input Type DC
Output Type Push-Pull, Totem Pole
Channel Output Current 25mA
Data Rate 5MBd
Propagation Delay tpLH / tpHL (Max) 300ns, 300ns
Rise and Fall Time 30ns, 7ns
Forward Voltage 1.5V
Continuous forward current- Max 10mA
Supply Voltage - Operating 4.5 V to 20 V
Temperature Range - Operating -40°C to 85°C
Mounting Through Hole
Case / Package 8-DIP
Win Source Part Number 016856-HCPL-2231-000E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 50
Family Name HCPL-2231
Introduction Date September 19, 2001
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian HCPL-2231-000E CAD Model

Description

The HCPL-2231-000E is a high-speed optoisolator that provides excellent performance with low input current.

  • Key Feature: High Voltage Isolation Barrier
  • Market Presence: High Popularity
  • Ideal For: High-Speed Switching with Low Power Consumption
  • Common Mode Transient Immunity: 1kV/μs
  • Channel Output Current: 25mA
