HCNW4506-500E Real Image HCNW4506-500E Real Image
Same model may have multiple batches, images only for reference.
HCNW4506-500E Real Image HCNW4506-500E Real Image
HCNW4506-500E Real Image HCNW4506-500E Real Image
Same model may have multiple batches, images only for reference.

HCNW4506-500E

Part No HCNW4506-500E
Manufacturer Broadcom Limited
Catalog Optoisolators - Logic Output
Description OPTOISO 5KV OPEN COLL 8DIP GW
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Active
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Isolation Voltage 5000Vrms
Common Mode Transient Immunity (Min) 15kV/μs
Input Type DC
Output Type Open Collector, Schottky Clamped
Channel Output Current 15mA
Propagation Delay tpLH / tpHL (Max) 550ns, 400ns
Forward Voltage 1.6V
Continuous forward current- Max 25mA
Supply Voltage - Operating 4.5 V to 30 V
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Case / Package 8-DIP Gull Wing
Win Source Part Number 016820-HCNW4506-500E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Quantity per package 750
Ultra Librarian 3D Model Ultra Librarian HCNW4506-500E CAD Model

Description

The Broadcom Limited 016820-HCNW4506-500E is a high-quality isolator that is designed to meet the needs of electronic enthusiasts and professionals. It is a popular product with balanced supply and demand status. The isolator is designed with an open collector and schottky clamped output type and can handle an isolation voltage of 5000Vrms. It has a temperature range of -40°C to 100°C and is made with high-quality materials. The product is a reliable choice for those who are looking for a high-quality isolator for their projects.
