ALM-2506-TR1G

Part No ALM-2506-TR1G
Manufacturer Broadcom Limited
Catalog RF Amplifiers
Description IC AMP LNA GPS CURR/SHTDN 2X2SMD
Datasheet
ALM-2506-TR1G Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer Broadcom Limited
Packaging Reel - TR
Status Obsolete(EOL)
Frequency 900MHz to 2.4GHz
P1dB 1.8dBm (1.5mW)
Gain 14.3dB
Noise Figure 0.8dB
RF Type GPS
Supply Voltage - Operating 1 V to 3.6 V
Operating Supply Current 8mA
Test Frequency 1575.42MHz
Case / Package 6-MCOB (2x2)
Win Source Part Number 078016-ALM-2506-TR1G
Family Name ALM-2506
Introduction Date February 08, 2010
ECCN EAR99
Country of Origin Malaysia
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ALM-2506-TR1G CAD Model

Description

ALM-2506-TR1G

The ALM-2506-TR1G is engineered to provide high efficiency and outstanding signal clarity in RF applications, offering a balance of power and performance.

  • Applications:
    • Cellular base stations
    • Broadcast transmitters
    • Military communication systems
  • Features and Benefits:
    • Enhanced durability for long-term operation
    • Optimized for minimal power loss, maximizing signal integrity
    • Customizable parameters to fit specific design needs
  • Additional Details: The ALM-2506-TR1G ensures compliance with industry standards, making it a reliable choice for complex RF environments.
