Same model may have multiple batches, images only for reference.
SRF1006-102Y Real Image
Same model may have multiple batches, images only for reference.

SRF1006-102Y

Part No SRF1006-102Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Datasheet
SRF1006-102Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr Bourns Inc.
Series SRF1006
Package Tape & Reel
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 1.4 kOhms @ 1 MHz
Inductance @ Frequency 1 mH @ 100 kHz
Current Rating (Max) 520mA
DC Resistance (DCR) (Max) 180mOhm
Voltage Rating - DC 50V
Temperature Range - Operating -40°C ~ 105°C
Mounting SMD (SMT)
Dimension 0.394" L x 0.343" W (10.00mm x 8.70mm)
Height (Max) 0.256" (6.50mm)
Package / Case Horizontal, 4 PC Pad
Base Product Number SRF1006
Other Names 118-SRF1006-102YCT,118-SRF1006-102YTR,118-SRF1006-102YDKR,SRF1006-102Y
Standard Package 800
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 1277157-SRF1006-102Y
Ultra Librarian 3D Model Ultra Librarian SRF1006-102Y CAD Model

Description

The Bourns Inc. SRF1006-102Y is a Common Mode Choke filter.

  • Voltage Rating: 50V
  • Current Rating (Max): 520mA
  • Impedance @ Frequency: 1.4 kOhms @ 1 MHz
  • Inductance @ Frequency: 1 mH @ 100 kHz
  • DC Resistance (DCR) (Max): 180mOhm
  • Height: 0.256" (6.50mm)
  • Mounting: SMD (SMT) tape and reel package
  • Package/Case: Horizontal, 4 PC pad case
  • Application: Ideal for use in signal line filters
  • Temperature Range: -40°C to 105°C
