Same model may have multiple batches, images only for reference.
SRF0905A-400Y Real Image
Same model may have multiple batches, images only for reference.

SRF0905A-400Y

Part No SRF0905A-400Y
Manufacturer Bourns Inc.
Catalog Common Mode Chokes
Datasheet
SRF0905A-400Y Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Filters>Common Mode Chokes
Mfr Bourns Inc.
Series SRF0905A
Package Tape & Reel
Filter Type Signal Line
Number of Lines 2
Impedance @ Frequency 800 Ohms @ 20 MHz
Inductance @ Frequency 40 µH @ 1 kHz
Current Rating (Max) 900mA
DC Resistance (DCR) (Max) 250mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 105°C
Ratings AEC-Q200
Mounting SMD (SMT)
Dimension 0.362" L x 0.236" W (9.20mm x 6.00mm)
Height (Max) 0.248" (6.30mm)
Package / Case Horizontal, 4 PC Pad
Base Product Number SRF0905A
Other Names SRF0905A-400YDKR,SRF0905A-400YTR,SRF0905A-400YCT
Standard Package 1,000
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8504.50.4000
Win Source Part Number 1277159-SRF0905A-400Y
Ultra Librarian 3D Model Ultra Librarian SRF0905A-400Y CAD Model

Description

The Bourns Inc. SRF0905A-400Y is a common mode choke with two lines and an impedance of 800 ohms at 20MHz.

  • Lines: Two lines
  • Impedance @ Frequency: 800 ohms @ 20MHz
  • Inductance @ Frequency: 40μH @ 1kHz
  • DC Resistance (Max): 250mΩ
  • Rating: AEC-Q200 rated
  • Temperature Range: -40°C to 105°C
  • Package/Case: Horizontal, 4 PC pad
  • Application: Ideal for use in signal line filtering applications
  • Packaging: Tape and reel package of 1000 units
  • ECCN: EAR99
  • REACH: Not affected by REACH
