CDSOT236-0502 Real Image
Same model may have multiple batches, images only for reference.

CDSOT236-0502

Part No CDSOT236-0502
Manufacturer Bourns Inc.
Catalog ESD and Circuit Protection
Description ESD Suppressor TVS 6-Pin SOT-23
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Breakdown Voltage 6 V
Capacitance 3.6 pF
Mounting SMD (SMT)
Case / Package SOT-23
Clamping Voltage 7.5 V
Contact Plating Tin
Depth 1.75 mm
Element Configuration Dual
Leakage Current 5 µA
Length 3.05 mm
Maximum Operating Temperature 125 °C
Max Surge Current 7 A
Min Operating Temperature -40 °C
Mount Surface Mount
Number of Channels 4
Number of Elements 1
Number of Pins 6
Operating Supply Voltage 5 V
Polarity Unidirectional
Radiation Hardening No
Reverse Breakdown Voltage 6 V
Reverse Standoff Voltage 5 V
RoHS Compliant
Termination SMD/SMT
Test Current 1 mA
Working Voltage 5 V
Win Source Part Number 1051733-CDSOT236-0502
Categories ESD and Circuit Protection
Manufacturer Bourns Inc.
Popularity Low
Supply and Demand Status Shortage
Ultra Librarian 3D Model Ultra Librarian CDSOT236-0502 CAD Model

Description

The CDSOT236-0502 is an SMD/SMT termination electronic component manufactured by Bourns Inc.

  • Category: ESD and Circuit Protection
  • Capacitance: 3.6 pF
  • Polarity: Unidirectional
  • Reverse Breakdown Voltage: 6V
  • Maximum Operating Temperature: 125°C
  • Minimum Operating Temperature: -40°C
  • Element Configuration: Dual
  • Breakdown Voltage: 6V
