Products specifications Report Issue?

Category Connectors, Interconnects>D-Sub Connectors
Mfr Amphenol ICC (Commercial Products)
Series FCC17
Package Box
Product Status Obsolete
Connector Style D-Sub
Connector Type Receptacle, Female Sockets
Number of Positions 15
Number of Rows 2
Mounting Type Through Hole
Shell Size, Connector Layout 2 (DA, A)
Contact Type Signal
Flange Feature Housing/Shell (Unthreaded)
Termination Solder
Shell Material, Finish Steel, Tin Plated
Contact Finish Gold
Contact Finish Thickness 15.0µin (0.38µm)
Material Flammability Rating UL94 V-0
Current Rating (Amps) 5A
Features Filter
Voltage Rating 200V
Color Black
Contact Form Machined
Dielectric Material Thermoplastic
Contact Material Phosphor Bronze
Temperature Range - Operating -40°C ~ 85°C
Base Product Number FCC17A15
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Other Names FCC17-A15SE-210
Standard Package 60
Win Source Part Number 1226150-FCC17A15SE210
Ultra Librarian 3D Model Ultra Librarian FCC17A15SE210 CAD Model

Description

The FCC17A15SE210 is a 15-position black D-sub connector from Amphenol ICC.

  • Positions: 15
  • Connector Type: D-sub
  • Color: black
  • Connector Type: receptacle
  • Gender: female sockets
  • Feature: filter
  • Contact Type: signal
  • Termination: solder
  • Contact Finish: gold with a thickness of 15.0µin (0.38µm)
  • Connector Form: machined
  • Contact Material: phosphor bronze
  • Voltage Rating: 200V
  • Current Rating: 5A
  • Shell Material: steel
  • Shell Plating: tin-plated
  • Dielectric Material: thermoplastic
  • Shell Size: 2 (DA, A)
  • Mounting Type: through-hole
  • Operating Temperature: -40°C to 85°C
  • Alternative Parts: FCC17-A15SE-210
  • Status: obsolete
  • RoHS: not RoHS compliant
