Category Circuit Protection - Transient Voltage Suppressors (TVS) - TVS Diodes
Mfr Amazing
Package Strip
Product Status Active
Type Zener
Bidirectional Channels 1
Voltage - Reverse Standoff (Typ) 8V (Max)
Voltage - Breakdown (Min) 9V
Power Line Protection No
Applications General
Temperature Range - Operating -55°C ~ 85°C (TC)
Mounting Type Surface Mount
Package / Case 0402 (1006 Metric)
Supplier Device Package DFN1006P2X
Standard Package 10 pcs
REACH Status Vendor Undefined
Win Source Part Number 722350-AZ4208-01F
Ultra Librarian 3D Model Ultra Librarian AZ4208-01F CAD Model

Description

The AZ4208-01F is a Zener type transient voltage suppressor diode designed for general circuit protection applications.

  • Diode Type: Zener TVS
  • Polarity: Bidirectional
  • Reverse Standoff Voltage (Max): 8V
  • Breakdown Voltage: 9V
  • Mounting Type: Surface Mount
  • Package: Strip
  • Standard Package Quantity: 10 pcs
  • Temperature Range: -55°C to 85°C (TC)
  • Manufacturer: Amazing
  • Product Status: Active
