Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Altera
Series Enpirion
Main Purpose DC/DC, Step Down
Outputs and Type 1, Non-Isolated
Voltage - Output 0.75 V ~ 3.3 V
Output Current 9A
Voltage - Input 4.5 V ~ 13.2 V
Regulator Topology Buck
Frequency - Switching 1MHz
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part EN2392QI
Win Source Part Number 773784-EVB-EN2392QI
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian EVB-EN2392QI CAD Model

Description

The Altera EN2392QI is a step-down DC/DC regulator.

  • Series: Enpirion
  • Output Voltage Range: 0.75 V to 3.3 V
  • Input Voltage Range: 4.5 V to 13.2 V
  • Outputs: 1 (non-isolated)
  • Switching Frequency: 1 MHz
  • Regulator Topology: Buck
  • Output Current: 9A
  • Package Includes: Board(s)
  • Utilized IC/Part: EN2392QI
  • Applications: Development boards, kits, and programmers
  • Popularity: Medium
  • Supply and Demand Status: Limited
