AP3 Altech corporation
Same model may have multiple batches, images only for reference.

AP3

Part No AP3
Manufacturer Altech corporation
Catalog Configurable Switch Components - Body
Description CONFIG SW BODY NON-ILLUM / Configurable Switch Body Pushbutton, Round Non-Illuminated
Datasheet
AP3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Switches - Configurable Switch Components - Body
Mfr Altech Corporation
Package Bulk
Product Status Active
Requires Contact Block(s)
Type Momentary
Illumination Non-Illuminated
Actuator Type Pushbutton, Round
(Select First, Then Apply Filters) Compatible Series Altech, 30mm
Panel Cutout Dimensions 30.5mm (Round)
Standard Package 2 pcs
MSL Level Not Applicable
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8538.90.8180
California Prop 65 Warning Information
Win Source Part Number 562918-AP3
Ultra Librarian 3D Model Ultra Librarian AP3 CAD Model

Description

The 562918-AP3 is a configurable switch body used in various electronic devices and systems. Bold the product name (e.g., BAV99S,135 → 562918-AP3) and manufacturer (e.g., Nexperia USA Inc. → Altech).

  • Switch Type: Momentary
  • Actuator: Round Pushbutton
  • Requires: Contact Blocks
  • Series: Altech 30mm
  • Package: Bulk (2 pieces)
  • ECCN: EAR99
  • REACH: Compliant
  • Panel Cutout: 30.5mm
  • Illumination: Non-Illuminated
