ACS716KLATR-6BB-T Real Image ACS716KLATR-6BB-T real image15018 ACS716KLATR-6BB-T Real Image
Same model may have multiple batches, images only for reference.
ACS716KLATR-6BB-T Real Image ACS716KLATR-6BB-T real image15018 ACS716KLATR-6BB-T Real Image
ACS716KLATR-6BB-T Real Image ACS716KLATR-6BB-T real image15018 ACS716KLATR-6BB-T Real Image
Same model may have multiple batches, images only for reference.

ACS716KLATR-6BB-T

Part No ACS716KLATR-6BB-T
Manufacturer Allegro MicroSystems, LLC
Catalog Current Transducers
Description SENSOR CURRENT HALL 6A AC/DC
Datasheet
ACS716KLATR-6BB-T Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Allegro MicroSystems, LLC
Packaging Reel - TR
Status Active
For Measuring AC/DC
Sensor Type Hall Effect, Open Loop
Current - Sensing 6A
Number of Channels 1
Output Ratiometric, Voltage
Sensitivity 100mV/A
Frequency DC to 120kHz
Linearity ±0.25%
Accuracy ±2.2%
Supply Voltage - Operating 3 V to 3.6 V
Response Time 4μs
Current - Supply (Max) 11mA
Temperature Range - Operating -40°C to 125°C
Polarization Bidirectional
Mounting SMD (SMT)
Dimension 16-SOIC (0.295", 7.50mm Width)
Win Source Part Number 1011848-ACS716KLATR-6BB-T
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Clock & Timing, Industrial
Ultra Librarian 3D Model Ultra Librarian ACS716KLATR-6BB-T CAD Model

Description

The Allegro MicroSystems ACS716KLATR-6BB-T is a ratiometric voltage output Hall Effect sensor that can measure AC/DC current sensing up to 6A.

  • Current Sensing: Up to 6A
  • Sensitivity: 100mV/A
  • Linearity: ±0.25%
  • Accuracy: ±2.2%
  • Voltage Supply: 3V to 3.6V
  • Operating Temperature: -40°C to 125°C
