UBC-DS31CD-MDA1E Real Image
Same model may have multiple batches, images only for reference.

UBC-DS31CD-MDA1E

Part No UBC-DS31CD-MDA1E
Manufacturer Advantech Corp
Catalog Embedded - Single Board Computers (SBCs)
Description COMPUTER ARM I.MX6 1GHZ 1GB DDR3 /
Datasheet
UBC-DS31CD-MDA1E Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Embedded Computers>Single Board Computers (SBCs), Computer On Module (COM)
Mfr Advantech Corp
Package Box
Core Processor ARM® Cortex®-A9, i.MX6Dual
Speed 1.0GHz
Number of Cores 2
Power (Watts) 2.3W
Cooling Type Heat Sink
Dimension 7.52" x 5.08" (191mm x 129mm)
Expansion Site/Bus Mini-PCIe, SIM
RAM Capacity/Installed 1GB/1GB
Storage Interface SDIO
Video Outputs HDMI, VGA
Ethernet 10/100/1000Mbps
USB USB (1)
RS-232 (422, 485) 1
Watchdog Timer Yes
Temperature Range - Operating 0°C ~ 40°C
Base Product Number UBC-DS31
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 5A002A1
HTSUS 8471.50.0150
Standard Package 1
Win Source Part Number 1209012-UBC-DS31CD-MDA1E
Ultra Librarian 3D Model Ultra Librarian UBC-DS31CD-MDA1E CAD Model

Description

The UBC-DS31CD-MDA1E is a single board computer designed for embedded computing applications.

  • Processor: ARM Cortex-A9 i.MX6Dual core 1.0GHz
  • RAM: 1GB
  • Storage Interface: SDIO
  • Ethernet: 10/100/1000Mbps
  • USB Port: Yes
  • Video Outputs: HDMI and VGA
  • RS-232 (422, 485) Port: Yes
  • Watchdog Timer: Yes
  • Cooling Type: Heat sink
  • Expansion Site/Bus: mini-PCIe and SIM
  • Operating Temperature: 0°C to 40°C
  • Power Consumption: 2.3W
  • Dimension: 7.52" x 5.08" (191mm x 129mm)
  • Suitable for: Single board computer and computer on module applications.
