Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Uncategorized
Manufacturer 3Peak
Popularity Medium
Supply and Demand Status Balance
Win Source Part Number 840805-TP2122-VR
Package Tape & Reel (TR);Cut Tape (CT)
Product Status Active
Amplifier Type Standard
Number of Circuits 2
Output Type Single Ended, Rail-to-Rail
Slew Rate 0.01 V/µs
Gain Bandwidth Product 18kHz
Current - Input Bias 1pA
Voltage - Input Offset 100µV
Current - Supply 600nA (x2 Channels)
Current - Output / Channel 20mA
Voltage - Supply Span (Min) 1.8 V
Voltage - Supply Span (Max) 6 V
Operating Temperature -40°C ~ 125°C
Grade -
Mounting Type Surface Mount
Package / Case 8-TSSOP, 8-MSOP (0.118", 3.00mm Width)
Supplier Device Package 8-MSOP
Ultra Librarian 3D Model Ultra Librarian TP2122-VR CAD Model

Description

The TP2122-VR is an operational amplifier designed for general-purpose applications.

  • Supply Voltage Range: 2.7V to 36V
  • Input Offset Voltage: 1mV
  • Manufacturer: 3Peak
  • Category: uncategorized
  • Supply and Demand Status: balance
