The M3DRK-3036J-ND is a 30-position (30x2) IDC (Insulation Displacement Connector) ribbon cable assembly from 3M. It's a pre-terminated cable designed for quick and reliable connections between circuit boards and other electronic components. The "ND" suffix typically indicates that the part is sold by Digi-Key Electronics.

Applications

• Internal Wiring in Electronic Equipment
• Prototype Development
• Data Transmission
• Signal Interconnection
• Panel Wiring

Features

• Number of Positions: 30 (Dual Row)
• Connector Type: IDC Ribbon Cable
• Cable Length: 36 inches (3 feet)
• Wire Gauge: Typically 28 AWG
• Connector Gender: Female to Female
• Pitch: 0.1 inch (2.54 mm)
• Cable Type: Flat Ribbon Cable

Benefits

• Quick and Easy Connections: IDC connectors allow for fast and reliable termination without soldering.
• Pre-Terminated: Reduces assembly time and eliminates the need for specialized tooling.
• Standard Pitch: Compatible with a wide range of standard headers and connectors.
• Organized Wiring: Ribbon cable provides a clean and organized wiring solution.
• Reliable Performance: 3M connectors are known for their quality and durability.

Additional Details

The M3DRK-3036J-ND cable assembly consists of two female IDC connectors attached to a 30-conductor flat ribbon cable. The IDC connectors are designed to pierce the insulation of the cable conductors, creating a gas-tight connection. This ensures a reliable and long-lasting electrical connection. The 0.1-inch pitch is a common standard for electronic connectors, making this cable assembly compatible with many different types of circuit boards and devices. The 36-inch length provides sufficient reach for connecting components within an enclosure. The 28 AWG wire gauge is suitable for carrying low to medium current signals.
