XFATM9B XFMRS Inc.
Same model may have multiple batches, images only for reference.

XFATM9B

Part No XFATM9B
Manufacturer XFMRS Inc.
Catalog Pulse Transformers
Description LAN XFMR 10/100 / 350μH LAN 10/100 Base-T Pulse Transformer 1CT:1CT Surface Mount
Datasheet
XFATM9B Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Transformers - Pulse Transformers
Mfr XFMRS Inc.
Package Tape & Reel
Product Status Active
Transformer Type LAN 10/100 Base-T
Inductance 350µH
Mounting Type Surface Mount
Size / Dimension 0.510" L x 0.385" W (12.95mm x 9.78mm)
Height - Seated (Max) 0.245" (6.22mm)
Temperature Range - Operating -40°C ~ 125°C
Standard Package 1 pcs
MSL Level 2 (1 Year)
ECCN EAR99
HTSUS 8504.50.8000
Win Source Part Number 699415-XFATM9B
Ultra Librarian 3D Model Ultra Librarian XFATM9B CAD Model

Description

The 699415-XFATM9B is a pulse transformer designed for use in LAN 10/100 Base-T applications.

  • Product: 699415-XFATM9B
  • Manufacturer:XFMRS Inc.
  • Application: LAN 10/100 Base-T applications
  • Size: 0.510" L x 0.385" W (12.95mm x 9.78mm)
  • Height: 0.245" (6.22mm)
  • Inductance: 350μH
  • Temperature Range: -40°C to 125°C
  • Mounting Type: Surface Mount
  • Package: Tape & Reel
  • Status: Active
