744833084075

Part No 744833084075
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 8.4MH 7.5A 3LN TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power Line
Number of Lines 3
Inductance @ Frequency 8.4 mH @ 10 kHz
Current Rating (Max) 7.5A
DC Resistance (DCR) (Max) 50mOhm
Voltage Rating - AC 500V
Temperature Range - Operating -40°C ~ 125°C
Mounting Type Through Hole
Size / Dimension 1.850" Dia (47.00mm)
Height (Max) 1.535" (39.00mm)
Case / Package Horizontal, 4 PC Pin
Package Tray
Supply and Demand Status Shortage
Win Source Part Number 1507027-744833084075
Ultra Librarian 3D Model Ultra Librarian 744833084075 CAD Model
