744212101 Wurth Electronics Inc – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

744212101

Part No 744212101
Manufacturer Wurth Electronics Inc
Catalog Common Mode Chokes
Description CMC 100UH 300MA 2LN 500 OHM SMD
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Filter Type Power, Signal Line
Number of Lines 2
Impedance @ Frequency 500 Ohms @ 60 MHz
Inductance @ Frequency 100 µH @ 100 kHz
Current Rating (Max) 300mA
DC Resistance (DCR) (Max) 220mOhm
Voltage Rating - DC 80V
Temperature Range - Operating -40°C ~ 105°C
Mounting Type Surface Mount
Size / Dimension 0.256" L x 0.142" W (6.50mm x 3.60mm)
Height (Max) 0.071" (1.80mm)
Case / Package Horizontal, 4 J-Lead
Package Tape & Reel
Supply and Demand Status Shortage
Win Source Part Number 1507227-744212101
Ultra Librarian 3D Model Ultra Librarian 744212101 CAD Model
