686130148922 Würth Elektronik
Same model may have multiple batches, images only for reference.

686130148922

Part No 686130148922
Manufacturer Wurth Electronics Inc
Catalog FFC, FPC (FlatFlexible) Connectors
Description CONN FFC FPC BOTTOM 30POS 1MM RA
Datasheet
686130148922 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Win Source Part Number WS1206821-686130148922
Manufacturer Würth Elektronik
Category Connectors, Interconnects -FFC, FPC (Flat Flexible) Connectors- FFC, FPC (Flat Flexible) Connector Assemblies
Series WR-FPC
Package Tape & Reel (TR) Cut Tape (CT)
Product Status Active
Flat Flex Type FFC, FPC
Mounting Type Surface Mount, Right Angle
Connector/Contact Type Contacts, Bottom
Number of Positions 30
Termination Solder
Ultra Librarian 3D Model Ultra Librarian 686130148922 CAD Model

Description

  • Flammability Rating: * UL94-VO
  • Contact Plating: 100u” Tin over 50u” Ni
  • Quality Class: 25 Mating Cycles
  • Operating Temp: - 25°C to +85°C
  • Compliance: Lead Free and RoHS
  • Current Rating: 1A
  • Working Voltage: 125V
  • UL Certified: E323964
  • Packaging: Tape and Reel
