VBPW34FAS Vishay VBPW34FAS label picture VBPW34FAS label picture 2 VBPW34FAS real image
Same model may have multiple batches, images only for reference.
VBPW34FAS Vishay VBPW34FAS label picture VBPW34FAS label picture 2 VBPW34FAS real image
VBPW34FAS Vishay VBPW34FAS label picture VBPW34FAS label picture 2 VBPW34FAS real image
Same model may have multiple batches, images only for reference.

VBPW34FAS

Part No VBPW34FAS
Manufacturer Vishay
Catalog Optical Sensors - Photodiodes
Description Photodiode PIN Chip 950nm 2-Pin SMD T/R / PHOTODIODE PIN HI SPEED HI SENS
Datasheet
VBPW34FAS Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Sensors, Transducers
Manufacturer Vishay
Packaging Reel - TR
Status Active
Wavelength 950nm
Spectral Range 780nm to 1050nm
Diode Type PIN
Response Time 100ns
Voltage - DC Reverse (Vr) (Max) 60V
Current - Dark (Typ) 2nA
Active Area 7.5mm²
Viewing Angle 130°
Temperature Range - Operating -40°C to 100°C
Mounting SMD (SMT)
Dimension 2-SMD, Z-Bend
Win Source Part Number 127273-VBPW34FAS
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name VBPW34FAS
Introduction Date August 26, 2009
ECCN EAR99
Country of Origin China
Halogen Free Compliant
Estimated EOL Date 2027
Ultra Librarian 3D Model Ultra Librarian VBPW34FAS CAD Model

Description

The Vishay VBPW34FAS is a PIN diode that is designed for use in sensors and transducers.

  • Maximum Reverse Voltage: 60V
  • Viewing Angle: 130 degrees
  • Mounting: Surface mount technology (SMT)
  • Response Time: 100ns
  • Spectral Range: 780nm to 1050nm
  • Active Area: 7.5mm²
  • Compliance: Halogen-free regulations
  • Estimated End-of-Life Date: 2027
  • Supply and Demand Status: Sufficient
