U290 InterFET Corporation
Same model may have multiple batches, images only for reference.

U290

Part No U290
Manufacturer Vishay
Catalog JFETs (Junction Field Effect)
Description JFET N-CH 30V TO206AC
Datasheet
U290 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - JFETs
Mfr Vishay
Package Tube
Product Status Obsolete
FET Type N-Channel
Voltage - Breakdown (V(BR)GSS) 30 V
Current - Drain (Idss) @ Vds (Vgs=0) 500 mA @ 10 V
Voltage - Cutoff (VGS off) @ Id 4 V @ 3 nA
Input Capacitance (Ciss) (Max) @ Vds 160pF @ 0V
Resistance - RDS(On) 3 Ohms
Power - Max 500 mW
Temperature Range - Operating -55°C ~ 150°C (TJ)
Mounting Type Through Hole
Package / Case TO-206AC, TO-52-3 Metal Can
Supplier Device Package TO-206AC (TO-52)
Base Product Number U290
Standard Package 200 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.21.0095
Win Source Part Number 692620-U290
Ultra Librarian 3D Model Ultra Librarian U290 CAD Model

Description

The 692620-U290 is an N-channel JFET transistor from Vishay.

  • Part Number: 692620-U290
  • Type: N-channel JFET transistor
  • Manufacturer: Vishay
  • Mounting: Through-hole
  • Package: TO-206AC (TO-52) metal can
  • Breakdown Voltage: 30V
  • Drain Current: 500mA @ 10V gate-source voltage
  • Cutoff Voltage: 4V @ 3nA drain current
  • On-Resistance: 3 Ohms
  • Input Capacitance: 160pF @ 0V drain-to-source voltage
  • Temperature Range: -55°C to 150°C
  • Applications: Amplifiers, switches, and voltage-controlled devices
