SQJB00EP-T1_GE3 Real Image SQJB00EP-T1_GE3 Real Image
Same model may have multiple batches, images only for reference.
SQJB00EP-T1_GE3 Real Image SQJB00EP-T1_GE3 Real Image
SQJB00EP-T1_GE3 Real Image SQJB00EP-T1_GE3 Real Image
Same model may have multiple batches, images only for reference.

SQJB00EP-T1_GE3

Part No SQJB00EP-T1_GE3
Manufacturer Vishay
Catalog FETs - Arrays
Description MOSFET 2 N-CH 60V POWERPAK SO8 / Mosfet Array 60V 30A (Tc) 48W Surface Mount PowerPAK? SO-8 Dual
Datasheet
SQJB00EP-T1_GE3 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Transistors - FETs, MOSFETs - FET, MOSFET Arrays
Mfr Vishay
Series Automotive, AEC-Q101, TrenchFET®
Package Tape & Reel
Product Status Active
Technology MOSFET (Metal Oxide)
Configuration 2 N-Channel (Dual)
Drain to Source Voltage (Vdss) 60V
Current - Continuous Drain (Id) @ 25°C 30A (Tc)
Rds On (Max) @ Id, Vgs 13mOhm @ 10A, 10V
Vgs(th) (Max) @ Id 3.5V @ 250µA
Gate Charge (Qg) (Max) @ Vgs 35nC @ 10V
Input Capacitance (Ciss) (Max) @ Vds 1700pF @ 25V
Power - Max 48W
Temperature Range - Operating -55°C ~ 175°C (TJ)
Mounting Type Surface Mount
Package / Case PowerPAK® SO-8 Dual
Supplier Device Package PowerPAK® SO-8 Dual
Base Product Number SQJB00
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.29.0095
Win Source Part Number 852969-SQJB00EP-T1_GE3
Ultra Librarian 3D Model Ultra Librarian SQJB00EP-T1_GE3 CAD Model

Description

The SQJB00EP-T1_GE3 is a MOSFET array from Vishay.

  • Configuration: Dual, N-Channel
  • Drain-to-Source Voltage: 60V
  • Continuous Drain Current: 30A
  • On-Resistance (Max): 13mOhm
  • Gate Threshold Voltage: 3.5V
  • Gate Charge: 35nC
  • Package: PowerPAK SO-8 Dual
  • Mounting Type: Surface Mount
  • Operating Temperature: -55°C to 175°C
  • Application: High Power
  • Product Status: Active
