Same model may have multiple batches, images only for reference.

IRCZ34PBF

Name: IRCZ34PBF
Brand: Vishay
SKU: 604171
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	IRCZ34PBF
Manufacturer	Vishay
Catalog	FETs - Single
Description	HEXFET Power MOSFET \| MOSFET N-CH 60V 30A TO-220-5
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Discrete Semiconductor Products
Manufacturer	Vishay Siliconix
Packaging	Tube
Status	Obsolete
Transistor Polarity	N-Channel
Technology	MOSFET
Vds - Drain-Source Breakdown Voltage	60V
Id - Continuous Drain Current	30A
Drive Voltage (Max Rds On, Min Rds On)	10V
Rds On (Maximum) at Id, Vgs	50mOhm at 18A, 10V
Gate Source Voltage(th) (Maximum) at Id	4V at 250μA
Gate Charge (Qg) (Maximum) at Vgs	46nC at 10V
Gate Source Voltage (Maximum)	±20V
Input Capacitance (Ciss) (Maximum) at Vds	1300pF at 25V
FET Feature	Current Sensing
Power Dissipation (Maximum)	88W
Temperature Range - Operating	-55°C ~ 175°C
Mounting Style	Through Hole
Supplier Device Package	TO-220-5
Manufacturer Package	TO-220-5
Manufacturer Pack Quantity	50
MSL Level	1 (Unlimited)
Win Source Part Number	1186859-IRCZ34PBF
Manufacturer Homepage	www.irf.com
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian IRCZ34PBF CAD Model

Description

The Vishay Siliconix MOSFET electronic component is a discontinued product with a popularity rating of medium. Its Win Source Part Number is 1186859-IRCZ34PBF.

Power Dissipation: 88W (maximum)
Supply and Demand Status: limited
Supplier Device Package: TO-220-5
