40CPQ080 Real Image
Same model may have multiple batches, images only for reference.

40CPQ080

Part No 40CPQ080
Manufacturer Vishay
Catalog Diodes, Rectifiers - Arrays
Description SCHOTTKY RECTIFIER | DIODE ARRAY SCHOTTKY 80V TO247AC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Vishay Semiconductor Diodes Division
Packaging Tube
Status Obsolete
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Maximum) 80V
Current - Average Rectified (Io) (per Diode) 20A
Voltage - Forward (Vf) (Maximum) at If 770mV at 20A
Speed Fast Recovery = 200mA (Io)
Current - Reverse Leakage at Vr 1.25mA at 80V
Operating Temperature - Junction -55°C ~ 175°C
Mounting Style Through Hole
Manufacturer Package TO-247-3
Supplier Device Package TO-247AC
Manufacturer Pack Quantity 500
MSL Level 1 (Unlimited)
Win Source Part Number 1128570-40CPQ080
Manufacturer Homepage www.irf.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 40CPQ080 CAD Model

Description

The 40CPQ080 is a Schottky diode that is known for its fast recovery of 200mA (Io).

  • Recovery: 200mA (Io)
  • Mounting: Through-hole
  • Package: TO-247AC
  • Voltage DC Reverse (Vr) Maximum: 80V
  • Voltage Forward (Vf) Maximum: 770mV @ 20A
  • Current Average Rectified (Io) (per diode): 20A
  • Diode Configuration: 1 pair common cathode
  • Operating Temperature: -55°C ~ 175°C
  • Manufacturer: Vishay Semiconductor Diodes Division
  • Win Source part number: 1128570-40CPQ080
