CR-05JL7----0R

Part No CR-05JL7----0R
Manufacturer Viking Tech
Catalog Chip Resistor - Surface Mount
Description RES 0 OHM JUMPER 1/8W 0805 / 0 Ohms Jumper 0.125W, 1/8W Chip Resistor 0805 (2012 Metric) Thick Film
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Resistors>Chip Resistor - Surface Mount
Manufacturer Viking Tech
Packaging Reel - TR
Resistance 0 Ohms
Tolerance Jumper
Power (Watts) 0.125W, 1/8W
Composition Thick Film
Temperature Range - Operating -55°C ~ 155°C
Case / Package 0805 (2012 Metric)
Supplier Device Package 0805
Size / Dimension 0.079" L x 0.049" W (2.00mm x 1.25mm)
Height - Seated (Max) 0.024" (0.60mm)
Number of Terminations 2
RoHS Status ROHS3 Compliant
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 5833.40.0000
Other Part Number 2577-CR-05JL7----0RTR
Standard Package 5,000
Win Source Part Number 1326111-CR-05JL7----0R
Ultra Librarian 3D Model Ultra Librarian CR-05JL7----0R CAD Model

Description

The CR-05JL7----0R is a chip resistor from Viking Tech.

  • Composition: Thick Film
  • Resistance: 0 Ohms
  • Power (Watts): 0.125W, 1/8W
  • Package / Case: 0805 (2012 Metric)
  • Number of Terminations: 2
  • Operating Temperature: -55°C to 155°C
  • Tolerance: Jumper
