Same model may have multiple batches, images only for reference.
OPB826S OPTEK Technologies
Same model may have multiple batches, images only for reference.

OPB826S

Part No OPB826S
Manufacturer TT Electronics
Catalog Optical Sensors
Description SENSOR OPT SLOT 2 NPN PCB MOUNT
Datasheet
OPB826S Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Sensors, Transducers - Optical Sensors - Photointerrupters - Slot Type - Transistor Output
Mfr TT Electronics
Package Bulk
Product Status Active
Sensing Distance 0.090" (2.29mm)
Sensing Method Through-Beam
Output Configuration 2 NPN
Current - DC Forward (If) (Max) 40 mA
Current - Collector (Ic) (Max) 30 mA
Voltage - Collector Emitter Breakdown (Max) 30 V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Through Hole
Package / Case PCB Mount
Type Unamplified
Base Product Number OPB826
Standard Package 100 pcs
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.49.8000
Win Source Part Number 651311-OPB826S
Ultra Librarian 3D Model Ultra Librarian OPB826S CAD Model

Description

The TT Electronics Photointerrupter is a reliable optical sensor for various electronic applications.

  • Mounting Type: Through-hole
  • Outputs: 2 NPN
  • Sensing Distance: 0.090" (2.29mm)
  • Operating Temperature Range: -40°C to 85°C
  • ECCN: EAR99
