TY-300P

Part No TY-300P
Manufacturer Triad Magnetics
Catalog Audio Transformers
Description AUDIO XFMR 600 / 600/600 TH
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Turns Ratio - Primary 1:2.48
Impedance - Primary (Ohms) 600
Impedance - Secondary (Ohms) 600/600
DC Resistance (DCR) - Primary 172Ohm
DC Resistance (DCR) - Secondary 66Ohm, 66Ohm
Transformer Type Data/Voice Coupling
Frequency Range 300Hz ~ 3.5kHz
Voltage - Isolation 1500VAC
Insertion Loss 0.8dB Typ
Return Loss 30dB Typ
Power Level -45dB ~ 7dB
Temperature Range - Operating -20°C ~ 85°C
Mounting Type Through Hole
Size / Dimension 0.812" L x 0.700" W (20.62mm x 17.78mm)
Height - Seated (Max) 0.740" (18.80mm)
Termination Style PC Pin
Package Bulk
Supply and Demand Status Shortage
Win Source Part Number 1511159-TY-300P
Ultra Librarian 3D Model Ultra Librarian TY-300P CAD Model
