UCC28180DR

Part No UCC28180DR
Manufacturer Texas Instruments
Catalog PMIC - PFC (Power Factor Correction)
Description Power Factor Correction Controller 0.075mA 18kHz to 250kHz 8-Pin SOIC T/R / IC PFC CTRLR AVERAGE CURR 8SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Mode Continuous Conduction (CCM)
Frequency - Switching 18kHz to 250kHz
Current - Startup 75μA
Supply Voltage - Operating 21V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 1115826-UCC28180DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name UCC28180
Introduction Date November 13, 2013
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian UCC28180DR CAD Model

Description

Overview of Texas Instruments UCC28180DR

The Texas Instruments UCC28180DR is a highly efficient, compact, and robust PWM (Pulse Width Modulation) controller designed for high-voltage power conversion applications. This advanced controller is part of TI's extensive family of power management integrated circuits, which are engineered to facilitate the development of reliable and high-performance power supplies.

Key Features

  • Wide-Range Operating Frequency: The UCC28180DR operates at a frequency range of 18 kHz to 250 kHz, allowing designers to optimize their systems for efficiency or size by selecting the appropriate frequency.
  • Multi-Mode Operation: It supports both continuous and discontinuous conduction modes, thereby enhancing its flexibility to cater to different power supply topologies and requirements.
  • High-Efficiency: With its advanced control methodologies, the device ensures high efficiency across a wide load range, making it suitable for energy-sensitive applications.
  • Voltage Feedforward Compensation: This feature provides improved line regulation and faster transient response, which is critical for maintaining stable output under varying input conditions.
  • Programmable Soft Start: The UCC28180DR includes programmable soft start functionality to limit inrush current during startup, which improves system reliability and lifespan.
  • Protection Features: It integrates multiple protection features such as overcurrent protection, overvoltage protection, and thermal shutdown, which safeguard the power supply and the end application from various fault conditions.

Applications

The UCC28180DR is versatile and can be used in a variety of applications, including but not limited to:

  • AC/DC power supplies for consumer electronics
  • Industrial power systems
  • Power adapters for portable devices
  • LED lighting systems
  • Telecommunication equipment power supplies

Package and Availability

Encased in an 8-pin SOIC package, the UCC28180DR is designed for simplified PCB layout and space-saving considerations. Texas Instruments ensures availability and support for their products, providing comprehensive technical documentation and design resources to assist engineers in integrating the UCC28180DR into their designs.

The UCC28180DR by Texas Instruments represents a reliable and versatile solution for modern power supply design challenges, offering a blend of performance, efficiency, and protection to meet the needs of a wide array of electronic applications.
