Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Driven Configuration Low-Side
Channel Type Independent
Number of Drivers 2
Gate Type N-Channel, P-Channel MOSFET
Supply Voltage - Operating 4 V to 15 V
Logic Voltage - VIL, VIH 1V, 2V
Current - Peak Output (Source, Sink) 4A, 4A
Input Type Non-Inverting
Rise and Fall Time 20ns, 15ns
Temperature Range - Operating -55°C to 150°C (TJ)
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 035764-UCC27424DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name UCC27424
Introduction Date February 15, 2004
ECCN EAR99
Country of Origin Malaysia, Mexico
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian UCC27424DR CAD Model

Description

Product Overview: Texas Instruments UCC27424DR

The UCC27424DR is a high-speed, dual-channel, low-side power MOSFET driver designed and manufactured by Texas Instruments. This device is engineered to deliver robust and efficient performance for a variety of applications requiring efficient power management and precision control.

Key Features

  • High Peak Output Current: Capable of delivering peak currents up to 4 A, the UCC27424DR ensures strong drive capability for a wide range of MOSFETs.
  • Dual Independent Channels: The device features two independent channels that can be used for driving two separate MOSFETs or for high-side and low-side driving in a half-bridge configuration.
  • Industry-Leading Rise and Fall Times: With rise and fall times typically under 15 ns, this driver enables fast switching, which is critical for reducing power losses and improving efficiency in power conversion systems.
  • Wide Supply Voltage Range: The driver operates over a supply voltage range of 4.5V to 15V, accommodating a variety of power stages and systems.
  • Input/Output Logic Compatibility: TTL and CMOS compatible input thresholds allow for easy interfacing with a range of signal levels, while robust output stages can drive capacitive loads without oscillation.
  • Thermal Shutdown: Integrated thermal shutdown protection helps prevent damage to the driver and the power stage under over-temperature conditions.

Applications

The UCC27424DR is ideal for a multitude of applications where efficient power switching is crucial. Common use cases include:

  • DC-to-DC converters
  • Motor controllers
  • Power inverters
  • Class-D audio amplifiers
  • Switch mode power supplies (SMPS)

Package and Quality

Offered in an 8-pin SOIC package, the UCC27424DR is designed for surface-mount technology (SMT), ensuring compact and reliable integration into circuit boards. Texas Instruments' commitment to quality means that this driver is produced in ISO-certified facilities, ensuring high reliability and performance consistency across batches.
