Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Tray
Resolution 12
Sampling Rate 550M
Number of Inputs 1
Input Type Differential
Data Interface Parallel
Configuration S/H-ADC
Number of Converters 1
Architecture Pipelined
Reference Type Internal
Operating Supply Voltage 3 V ~ 3.6 V, 5V
Voltage - Supply, Digital 3 V ~ 3.6 V
Operating Temperature Range -40°C ~ 85°C
Package 80-TQFP Exposed Pad
Manufacturer Package 80-HTQFP (12x12)
Win Source Part Number 1141751-ADS54RF63IPFP
Manufacturer Homepage www.ti.com
Family Name ADS54RF63
Introduction Date August 01, 2008
ECCN 3A001.a.5.a.3
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADS54RF63IPFP CAD Model

Description

Introducing the ADS54RF63IPFP from Texas Instruments

The ADS54RF63IPFP is a high-performance, dual-channel, 12-bit, 500 MSPS analog-to-digital converter (ADC) that brings together innovative design and cutting-edge technology from Texas Instruments. This ADC is designed to cater to a broad range of applications, including wireless communications, test and measurement equipment, and radar systems, where high-speed data conversion is crucial.

At the heart of the ADS54RF63IPFP lies a state-of-the-art sampling architecture that enables the simultaneous sampling of two analog input channels, ensuring phase coherence and excellent dynamic performance. The device is capable of operating at a conversion rate of up to 500 mega samples per second, providing the precision and speed required for demanding signal processing tasks.

The ADC features a flexible input range, which can be adjusted to accommodate various signal levels, thereby optimizing performance for specific applications. The digital output is formatted in an easy-to-interface LVDS (Low-Voltage Differential Signaling) standard, which minimizes signal integrity issues and facilitates high-speed data transfer.

With an integrated digital down-converter (DDC), the ADS54RF63IPFP enhances system performance by reducing data rate and simplifying the digital interface to downstream digital signal processors (DSPs). The DDC includes features such as a numerically controlled oscillator (NCO), decimation filters, and complex mixer, which significantly offloads processing tasks from the DSP and streamlines system design.

Reliability is a key factor in the design of the ADS54RF63IPFP, and it is built to meet the rigorous standards of industrial applications. The device is housed in a compact 80-pin HTQFP (Heat Sink Thin Quad Flat Package) that ensures efficient thermal management and saves valuable board space.

The ADS54RF63IPFP is supported by a range of development tools and software from Texas Instruments, including evaluation modules and reference designs, which help accelerate the design cycle and enable engineers to bring their products to market faster.

In summary, the ADS54RF63IPFP from Texas Instruments is an ADC that offers exceptional performance and flexibility, making it an ideal choice for high-speed data acquisition systems that require the highest levels of accuracy and reliability.
