Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Maxim Integrated
Packaging Tube/Rail
Status Active
Display Type LED
Configuration 7 Segment + DP
Digits or Characters 8 Digits
Operating Supply Current 330mA
Supply Voltage - Operating 4 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting Through Hole
Case / Package 24-PDIP
Win Source Part Number 073988-MAX7221CNG+
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name MAX7221
Introduction Date July 01, 1997
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2030
Ultra Librarian 3D Model Ultra Librarian MAX7221CNG+ CAD Model

Description

Maxim Integrated MAX7221CNG+ Serially Interfaced, 8-Digit LED Display Driver

The MAX7221CNG+ from Maxim Integrated is a compact, serial input/output common-cathode display driver that interfaces microprocessors to 7-segment numeric LED displays of up to 8 digits, bar-graph displays, or 64 individual LEDs. Included on-chip are a BCD code-B decoder, multiplex scan circuitry, segment and digit drivers, and an 8x8 static RAM that stores each digit. The MAX7221CNG+ is designed to minimize the need for external components, simplifying the design and layout process for display systems.

One of the key features of the MAX7221CNG+ is its SPI, QSPI, and MICROWIRE compatibility, which allows for easy integration with most microcontrollers. The device also includes a slew-rate limited segment driver, which reduces EMI and eliminates the need for external resistors. This makes it an excellent choice for applications in which power consumption and noise are critical concerns.

With its built-in digital brightness control, the MAX7221CNG+ allows users to adjust the intensity of the LED display from a 1/16 duty cycle up to a 31/16 duty cycle. This feature is particularly useful in battery-powered applications where varying light conditions require the display brightness to be adjusted accordingly.

The device operates from a 4.0V to 5.5V power supply, ensuring compatibility with a wide range of digital systems. Its -40°C to +85°C temperature range makes it suitable for use in harsh environments. The MAX7221CNG+ is packaged in a 24-pin DIP configuration, which is conducive to prototyping and can be easily mounted on a standard breadboard or PCB.

Overall, the MAX7221CNG+ is a versatile and reliable choice for designers looking to implement LED displays in their systems. Its ease of use, combined with its feature set, makes it a popular choice for applications such as panel meters, digital clocks, and other electronic devices that require dynamic visual feedback.
