Products specifications Report Issue?

Category Integrated Circuits (ICs)>Interface - Signal Buffers, Repeaters, Splitters
Mfr Texas Instruments
Package Tape & Reel (TR)
Applications USB
Data Rate (Max) 480Mbps
Number of Channels 3
Signal Conditioning Input Equalization
Capacitance - Input 2.5 pF
Voltage - Supply 2.3V ~ 6.5V
Current - Supply 22mA
Temperature Range - Operating 0°C ~ 70°C (TA)
Mounting SMD (SMT)
Package / Case 12-XFQFN
Supplier Device Package 12-X2QFN (1.6x1.6)
Base Product Number TUSB216
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 296-TUSB216RWBRTR
Standard Package 3,000
Win Source Part Number 964804-TUSB216RWBR
Ultra Librarian 3D Model Ultra Librarian TUSB216RWBR CAD Model

Description

The TUSB216RWBR is a high-performance USB 2.0 high-speed signal conditioner, designed by the renowned semiconductor manufacturer, Texas Instruments. This advanced IC is specifically engineered to enhance signal quality by performing pre-emphasis and equalization on the data lines, which mitigates signal degradation caused by long cables and PCB traces. With the TUSB216RWBR, users can expect an improved user experience with USB 2.0 connections, ensuring reliable data transmission and connectivity in a variety of applications.

Key Features

  • Signal Conditioning: The device offers advanced signal conditioning capabilities, which include transmit pre-emphasis and receive equalization. These features help to extend the reach of USB 2.0 signals without compromising data integrity.
  • Compatibility: It is backward compatible with USB 1.1 and supports low-speed, full-speed, and high-speed data rates, making it a versatile solution for a wide range of USB-enabled devices.
  • Automatic Adjustment: The TUSB216RWBR can automatically adjust the level of signal conditioning based on the quality of the signal it receives, ensuring optimal performance without the need for manual tuning.
  • Power Efficiency: This device is designed for low-power operation, making it an ideal choice for battery-powered applications. It also supports USB suspend, resume, and remote wakeup features for improved power management.
  • Integration: The IC is available in a compact QFN package, allowing for easy integration into existing designs without requiring significant PCB space.

Applications

The TUSB216RWBR is suitable for a broad spectrum of USB-related applications. It is particularly beneficial in scenarios where signal integrity might be compromised due to factors such as long cable distances or complex PCB layouts. Typical applications include but are not limited to:

  • Desktop and laptop computers
  • Docking stations and port replicators
  • USB hubs, peripherals, and accessories
  • Industrial control and automation systems

With its ability to ensure robust and reliable USB connectivity, the TUSB216RWBR is an essential component for any design requiring consistent USB 2.0 performance.
