Overview of TUSB2036VFRG4

The TUSB2036VFRG4 is a highly integrated USB 2.0 compliant hub designed by Texas Instruments for managing USB data transfers and connectivity. This versatile device is perfect for expanding the number of USB ports available on a computer or other USB host devices. It can connect up to three USB devices while ensuring seamless communication between the host and the connected peripherals.

Key Features

• USB Interface: The hub supports USB 2.0 high-speed and full-speed signals, offering a maximum data transfer rate of 480 Mbps when operating in high-speed mode.
• Port Count: It features three downstream ports for device connection, providing an efficient solution for expanding the USB capabilities of an electronic system.
• Power Management: The TUSB2036VFRG4 includes power management options, such as global suspend and per-port power control, which help in reducing overall power consumption.
• Overcurrent Protection: Each downstream port is equipped with overcurrent sensing and individual overcurrent protection, ensuring the safety of connected devices.
• Integrated Oscillator: The device has an integrated 6 MHz oscillator which reduces the need for external components, simplifying design and saving board space.

Applications

Due to its compact size and comprehensive feature set, the TUSB2036VFRG4 is suitable for a wide range of applications. It can be used in desktop and notebook PCs, docking stations, monitors with USB ports, standalone USB hubs, and various other USB-enabled devices that require additional port expansion.

Design and Packaging

The TUSB2036VFRG4 comes in a 32-pin QFN package, making it ideal for space-constrained applications. Its small footprint allows for easy integration into system designs without significant impact on the overall size of the end product.

Quality and Reliability

As with all Texas Instruments products, the TUSB2036VFRG4 is manufactured to high-quality standards, ensuring reliability and performance in demanding environments. TI's commitment to quality makes this USB hub controller a dependable choice for designers looking to enhance their systems with additional USB connectivity.
