The TS5A23157RSER is a high-performance, dual 1:2 multiplexer/demultiplexer designed by Texas Instruments for signal routing applications that require low on-state resistance, low crosstalk, and are bidirectional in nature. This versatile device is suitable for a range of applications, including signal gating, switching, and routing in communication, computing, and consumer electronics.

Key Features

• Low On-State Resistance: The device offers a typical on-state resistance of just 0.5 ohms, providing efficient signal transmission with minimal signal loss.
• Wide Operating Voltage Range: TS5A23157RSER operates over a broad voltage range of 1.65 to 5.5 V, ensuring compatibility with various logic levels and providing design flexibility.
• Low Crosstalk: Engineered to minimize interference between channels, this multiplexer/demultiplexer ensures clean, reliable signal routing.
• Break-Before-Make Switching: This feature prevents signal overlap during channel transitions, thereby avoiding shorting and signal corruption.
• Bidirectional Data Flow: The device supports bidirectional data flow, making it ideal for both multiplexing and demultiplexing applications.

Applications

The TS5A23157RSER is widely used in a variety of applications, including:

• Data Communication
• Signal Gating
• Audio and Video Switching
• Function Generators
• Relay Replacement

Product Specifications

Ordering Information

The TS5A23157RSER is available for order in various quantities and packaging options. For detailed ordering and shipping information, consult the Texas Instruments website or contact an authorized distributor.
