Products specifications Report Issue?

Categories Integrated Circuits (ICs)
Manufacturer Texas Instruments
Packaging Reel - TR
Applications USB
Switch Circuit DP3T
Number of Channels 1
On-State Resistance (Maximum) 7 Ohm
Operating Supply Voltage 2.5 V ~ 4.3 V
-3db Bandwidth 6.5GHz
Features USB 2.0
Operating Temperature Range -40°C ~ 85°C (TA)
Package 12-WFQFN
Manufacturer Package 12-WQFN (1.8x1.8)
Win Source Part Number 1274331-TS3USB3031RMGR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Family Name TS3USB3031
Introduction Date July 03, 2013
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian TS3USB3031RMGR CAD Model

Description

Product Overview: TS3USB3031RMGR

The TS3USB3031RMGR is a high-performance, integrated switch designed by Texas Instruments to cater to the advanced requirements of USB 3.0 data and power multiplexing. This product is part of the Texas Instruments portfolio of switch ICs that are engineered to provide efficient, seamless switching between various data and charging interfaces.

Key Features

  • USB 3.0 Compatibility: The device supports SuperSpeed USB 3.0 signals, ensuring fast data transfer rates of up to 5 Gbps, which is essential for applications requiring quick data synchronization and file transfers.
  • Low On-Resistance: With a low on-resistance of typically 4.5 ohms for the data switch and 6 ohms for the power switch, the TS3USB3031RMGR ensures minimal signal attenuation, providing a reliable and efficient signal routing solution.
  • Power Multiplexing: The switch allows for the multiplexing of USB 3.0 or USB 2.0 data lines with additional power or sideband use, offering versatility for various USB configurations and applications.
  • ESD Protection: Integrated Electrostatic Discharge (ESD) protection circuits safeguard the device against static damage, enhancing its robustness and longevity in consumer electronics that are frequently connected and disconnected.
  • Space-Saving Design: Housed in a compact 16-pin UQFN package, the TS3USB3031RMGR is ideal for space-constrained applications, enabling designers to maintain a small form factor in their designs.

Applications

The TS3USB3031RMGR is suitable for a wide range of applications, including but not limited to:

  • Smartphones and tablets
  • Laptops and Ultrabooks
  • Desktop computers and workstations
  • USB hubs and docking stations
  • Peripheral devices requiring USB connectivity

Technical Specifications

Below are some of the technical specifications that make the TS3USB3031RMGR a reliable choice for designers and engineers:

  • Supply Voltage: Operating between 2.3V and 4.3V, it can easily integrate into various system power schemes.
  • Bandwidth: The switch offers a wide bandwidth to accommodate the high-speed data rates of USB 3.0 signals.
  • Temperature Range: The device is operational over an extended temperature range, making it suitable for use in diverse environments.

Overall, the TS3USB3031RMGR from Texas Instruments is a versatile, high-performance solution for USB data and power switching applications, offering reliability, speed, and integration ease for designers across various industries.
