Product Overview: Texas Instruments TPS3705-50DR

The TPS3705-50DR is a high-precision supply voltage supervisor designed by Texas Instruments, tailored to monitor dual-supply systems. This device is a crucial component for applications that require a high degree of reliability and accuracy in voltage monitoring, ensuring system stability and functionality under various conditions.

Key Features

• Dual Voltage Monitoring: The TPS3705-50DR can simultaneously monitor two supply voltages, making it an ideal choice for systems with multiple power domains.
• Programmable Reset Delay: It features an externally programmable time delay for the reset signal, providing designers with flexibility to accommodate different system requirements.
• Low Supply Current: With a typical supply current of 40 µA, this device is optimized for power-sensitive applications.
• Precision Thresholds: The voltage thresholds are highly precise, ensuring accurate monitoring and reliable operation.
• Manual Reset Input: A manual reset input allows for a system reset to be initiated by an external signal, offering additional control to the system operators.

Applications

The TPS3705-50DR is versatile and can be used in a wide range of applications, including:

• Industrial control systems
• Portable and battery-powered electronics
• Microprocessor or microcontroller-based systems
• Automotive electronics
• Communication equipment

Technical Specifications

• Package: 8-SOIC (0.154", 3.90mm Width)
• Output Type: Push-Pull, Totem Pole
• Threshold Voltage: 4.55V, 2.93V
• Operating Temperature: -40°C to +85°C
• Reset Timeout: Adjustable by an external capacitor

The TPS3705-50DR is designed for systems that cannot afford to compromise on power supply integrity. With its precision voltage monitoring and customizable features, it ensures that your system operates within safe voltage levels, protecting against potential damage due to irregular power supply conditions.
