Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Hot Plug Controller
Number of Channels 6
Internal Switch(s) Both
Applications PCI Express
Features Latched Fault, SMBus, Thermal Limit, UVLO
Programmable Features Current Limit, Fault Timeout, Slew Rate
Supply Voltage - Operating 3 V to 3.6 V, 10.8 V to 13.2 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 48-TQFP (7x7)
Win Source Part Number 1111458-TPS2363PFBR
Family Name TPS2363
Introduction Date April 12, 2005
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS2363PFBR CAD Model

Description

The TPS2363PFBR is a sophisticated integrated circuit from Texas Instruments, designed to provide comprehensive power management solutions for a wide array of applications. This particular chip is part of the TPS236x family of Hot Swap Power Managers, which are engineered to enable the safe insertion and removal of circuit boards from live backplanes and power buses. The TPS2363PFBR is encapsulated in a compact PFB package, making it suitable for space-constrained environments.

Key Features

  • Integrated Hot Swap Control: This feature allows the device to manage inrush current during board insertion, preventing glitches and surges that could potentially damage sensitive electronic components.
  • Programmable Current Limit: The TPS2363PFBR offers the ability to set a current limit threshold, which is critical for protecting the power supply and the load from overcurrent conditions.
  • Under-Voltage and Over-Voltage Protection: The device ensures the power supply remains within safe operating limits, safeguarding the system against voltage anomalies.
  • Power Good (PG) Output: This output provides a real-time status indicator, which can be used to enable downstream converters when stable power is confirmed.

Applications

The versatility of the TPS2363PFBR makes it an ideal choice for a variety of applications, including:

  • Network Routers and Switches
  • Servers and Storage Systems
  • Industrial Equipment
  • Telecommunications Infrastructure

Technical Specifications

Parameter Value Package Type PFB Operating Temperature -40°C to 85°C Input Voltage Range 2.7V to 5.5V Current Limit Accuracy ±10%

For designers and engineers looking for a reliable power management solution, the TPS2363PFBR by Texas Instruments offers an array of features that ensure stable and safe operation in various electronic systems. Its robust protection features and programmable parameters make it a versatile component for managing power requirements efficiently.
