TPL0202-10MRTER

Part No TPL0202-10MRTER
Manufacturer Texas Instruments
Catalog Data Acquisition - Digital Potentiometers
Description IC DGTL POT 256POS 10K DL 16WQFN
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Taper Linear
Configuration Potentiometer
Number of Circuits 2
Number of Taps 256
Resistance (Ohms) 10k
Supply Voltage - Operating 2.7 V to 5.5 V
Tolerance ±20%
Temperature Coefficient (Typ) 132 ppm/°C
Resistance - Wiper (Ohms) (Typ) 25
Temperature Range - Operating -40°C to 85°C
Case / Package 16-WQFN (3x3)
Win Source Part Number 088119-TPL0202-10MRTER
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian TPL0202-10MRTER CAD Model

Description

The TPL0202-10MRTER from Texas Instruments is a highly precise, dual-channel digital potentiometer designed to offer a reliable and flexible solution for a wide range of applications. This integrated circuit (IC) features non-volatile memory and an SPI interface, making it an ideal choice for applications requiring digital resistance trimming or adjustments, such as in audio processing, industrial control systems, and communication devices.

Key Features

  • Dual-Channel: The TPL0202-10MRTER contains two independently programmable potentiometers, providing versatility and multi-functionality within a single package.
  • 256 Wiper Positions: Each potentiometer channel offers 256 resistive steps, allowing for fine-tuning and precise adjustments to the resistance settings.
  • Non-Volatile Memory: With integrated non-volatile memory, the device retains the wiper position after power cycling, ensuring consistent performance and settings retention.
  • SPI Interface: The device's Serial Peripheral Interface (SPI) ensures easy communication with microcontrollers or other digital systems, providing a straightforward means of control and configuration.
  • Low Wiper Resistance: The TPL0202-10MRTER boasts low wiper resistance, which minimizes the impact on the overall resistance and ensures better performance.
  • Wide Operating Voltage Range: The device operates over a broad voltage range, accommodating various power supply requirements and enhancing its adaptability to different system voltages.
  • Compact Package: Housed in a small form factor, the TPL0202-10MRTER is suitable for space-constrained applications without compromising functionality.

Applications

The TPL0202-10MRTER is well-suited for a variety of applications, including but not limited to:

  • Adjustable power supplies
  • Audio equipment equalization
  • Calibration and tuning in industrial automation systems
  • Communication system signal adjustments

Quality and Reliability

As with all Texas Instruments products, the TPL0202-10MRTER is manufactured to high standards, ensuring reliability and performance consistency. Its robust design and quality materials make it a dependable choice for engineers and designers looking for a digital potentiometer solution.
