Products specifications Report Issue?

Categories Circuit Protection
Estimated Pruduction Lead Time 34 Weeks
Features 13V (Typ) Clamp 5A (8/20µs) Ipp Tvs Diode Surface Mount 4-X2SON (0.8x0.8)
Manufacturer Texas Instruments
Package Reel - TR
Operating Temperature Range -40°C ~ 125°C (TA)
Mounting Surface Mount
Package 4-XFDFN Exposed Pad
Case / Package 4-X2SON (0.8x0.8)
Family Name TPD4E110
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8541.10.0080
Other Part Number TPD4E110DPWR-ND, 296-38345-6, 296-38345-1, 296-38345-2
Quantity per package 3000
Popularity High
Supply and Demand Status Balance
Win Source Part Number 900637-TPD4E110DPWR
Ultra Librarian 3D Model Ultra Librarian TPD4E110DPWR CAD Model

Description

Product Overview: TPD4E110DPWR from Texas Instruments

The TPD4E110DPWR is a state-of-the-art transient voltage suppressor (TVS) diode array from Texas Instruments, designed to protect sensitive electronic circuits from electrostatic discharge (ESD) and other voltage-induced transient events. This device is particularly well-suited for safeguarding high-speed data lines and I/O ports in a wide range of applications, including consumer electronics, mobile devices, and industrial equipment.

Key Features

  • ESD Protection: The TPD4E110DPWR offers robust ESD protection for sensitive components, meeting IEC 61000-4-2 (Level 4) standards. It can withstand ESD strikes of ±10kV (Contact Discharge) and ±15kV (Air-Gap Discharge), ensuring the longevity and reliability of your device.
  • Low Capacitance: With a low loading capacitance of 0.6 pF per channel, this TVS diode array is ideal for protecting high-speed data lines without compromising signal integrity.
  • Multi-Channel Integration: The device features four channels of ESD protection, allowing for compact and efficient design by reducing the number of components required on a PCB.
  • Small Package Size: Housed in a tiny 10-pin DFN package (DPWR suffix), the TPD4E110DPWR minimizes board space and is well-suited for space-constrained applications.
  • Wide Operating Voltage Range: It supports a wide operating voltage range, catering to various interface standards and ensuring versatility across different platforms.

Applications

The TPD4E110DPWR is highly versatile and can be used in a multitude of applications, including:

  • USB interfaces
  • HDMI ports
  • DisplayPort interfaces
  • LVDS lines
  • Serial-ATA (SATA) ports
  • Other high-speed data and signal lines

Quality and Reliability

Texas Instruments is renowned for its commitment to quality and reliability, and the TPD4E110DPWR is no exception. It is built with stringent manufacturing standards and rigorous testing protocols to ensure it meets the demands of even the most challenging environments. When you choose this TVS diode array, you can be confident that you are selecting a product that will provide superior protection for your electronic designs.
