Products specifications

Category Development Boards, Kits, Programmers - Evaluation Boards - Embedded - MCU, DSP
Mfr Texas Instruments
Series Hercules™
Package Bulk
Product Status Obsolete
Board Type Evaluation Platform
Type MCU 32-Bit
Core Processor ARM® Cortex®-R4F
Platform controlCARD
Utilized IC / Part TMS570LS
Mounting Type Fixed
Contents Board(s)
Base Product Number TMDX570
Standard Package 1
RoHS Status Not applicable
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN 3A991A2
HTSUS 8473.30.1180
Win Source Part Number 1341923-TMDX570LS31CNCD
Ultra Librarian 3D Model Ultra Librarian TMDX570LS31CNCD CAD Model

Description

The TMDX570LS31CNCD from Texas Instruments is a highly capable development tool designed to unleash the potential of the Hercules™ TMS570LS31x series of microcontrollers. This device is specifically engineered for safety-critical applications, making it an ideal choice for industries such as automotive, industrial, and avionics, where reliability and performance are paramount.

Key Features

  • High-Performance ARM Cortex-R4F Core: At the heart of the TMDX570LS31CNCD is a 32-bit ARM Cortex-R4F CPU that operates at frequencies up to 330 MHz, delivering the computational power needed for complex tasks and control algorithms.
  • Integrated Safety Features: The microcontroller includes built-in safety features such as ECC (Error Correcting Code) on both flash and RAM, lockstep CPU, and built-in self-test capabilities, providing a robust foundation for developing safety-critical systems.
  • Extensive Communication Interfaces: With a range of communication interfaces including CAN, FlexRay, Ethernet, LIN, and SPI, this development kit ensures seamless integration with a variety of peripherals and networks, enabling versatile system designs.
  • Advanced Memory Architecture: Equipped with up to 3MB of integrated flash memory and 256KB of data RAM, the TMDX570LS31CNCD can handle extensive code and data storage requirements for demanding applications.
  • Rich Peripheral Set: The device boasts a comprehensive set of peripherals such as high-resolution PWMs, 12-bit ADCs, and multi-buffered SPIs, providing the tools necessary for precise control and monitoring tasks.

Development Support and Software

The TMDX570LS31CNCD is supported by Texas Instruments' extensive software development ecosystem. This includes the HALCoGen peripheral driver generation tool, the safety-certified Hercules Development Kit (HDK) software, and the Code Composer Studio™ integrated development environment (IDE). These tools greatly simplify the development process and help accelerate time-to-market for your safety-critical applications.

Applications

Given its robust feature set and compliance with stringent safety standards, the TMDX570LS31CNCD is well-suited for a wide range of applications, including:

  • Automotive systems such as ABS, airbags, and power steering
  • Industrial control systems and robotics
  • Avionics, including flight control and engine management systems
  • Railway communications and control systems
