TLC5916IN

Part No TLC5916IN
Manufacturer Texas Instruments
Catalog PMIC - LED Drivers
Description IC LED DRIVER LINEAR 120MA 16DIP  /  LED Driver IC 8 Output Linear Shift Register Dimming 120mA 16-PDIP
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>PMIC - LED Drivers
Mfr Texas Instruments
Package Tube
Type Linear
Topology Shift Register
Internal Switch(s) Yes
Number of Outputs 8
Voltage - Supply (Min) 3V
Voltage - Supply (Max) 5.5V
Voltage - Output 20V
Current - Output / Channel 120mA
Frequency 30MHz
Applications Signage
Temperature Range - Operating -40°C ~ 125°C (TA)
Mounting Type Through Hole
Package / Case 16-DIP (0.300", 7.62mm)
Supplier Device Package 16-PDIP
Base Product Number TLC5916
Other Names 296-24383-5,-296-24383-5,-296-24383-5R,296-24383-5R,-TLC5916INE4R,-TLC5916INR,-TLC5916INE4,TLC5916IN
Standard Package 25
MSL Level 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 1253374-TLC5916IN
Ultra Librarian 3D Model Ultra Librarian TLC5916IN CAD Model

Description

Product Overview: Texas Instruments TLC5916IN

The TLC5916IN is a highly efficient, 8-bit constant current LED sink driver designed and manufactured by Texas Instruments (TI), a leader in semiconductor solutions. This integrated circuit is specifically tailored for LED display applications and is capable of providing uniform and constant current for driving LEDs, which is essential for maintaining consistent brightness across the display.

Key Features

  • Constant Current Output: The TLC5916IN ensures a consistent current of up to 120 mA across all output channels, which can be adjusted through an external resistor.
  • 8-Bit Shift Register & Latch: It includes an 8-bit serial-in, parallel-out shift register and an 8-bit D-type storage latch to manage LED brightness and create various lighting effects.
  • Wide Voltage Range: The device operates over a wide supply voltage range from 3.0 V to 5.5 V, making it versatile for various LED display systems.
  • Error Detection: It features an error detection mode that senses open LED errors, enhancing the reliability of the LED display system.
  • Thermal Shutdown: The built-in thermal shutdown feature protects the device from overheating, thereby ensuring long-term reliability and safety.

Applications

The TLC5916IN is ideal for a broad range of applications where LED displays are utilized. This includes:

  • Instrument panels and infotainment displays in automotive
  • Indoor and outdoor LED panels
  • LED-based message and sign boards
  • Industrial control indicators
  • Consumer electronics

Technical Specifications

With a 30 MHz clock frequency, the TLC5916IN provides fast data transfer rates. The device comes in a 16-pin DIP (Dual In-line Package) that is easy to integrate into various circuit designs. Its robust design ensures that it can withstand the rigors of continuous operation in a wide range of environmental conditions.

Conclusion

The Texas Instruments TLC5916IN is a reliable and efficient solution for driving LED displays. Its constant current output, error detection capabilities, and thermal protection make it a highly desirable component for designers looking to create high-performance LED display systems.
