The TCA9509DGKR is a robust level translating I²C-bus and SMBus buffer that enables bidirectional voltage-level translation in mixed-mode I²C-bus applications. Manufactured by Texas Instruments, this integrated circuit is designed to ensure seamless communication between devices operating at different voltage levels within a system.

Key Features

• Level Translation: The TCA9509DGKR facilitates level translation between 1.8V, 2.5V, 3.3V, and 5V buses, which makes it highly versatile for interfacing between low voltage and higher voltage components.
• Two-Channel Bidirectional Buffer: It has two bidirectional channels which allow for simultaneous transmit and receive operations, ensuring efficient data flow in both directions.
• High-Speed Operation: This device supports fast-mode I²C-bus devices and multiple masters, with a maximum data rate of 1 Mbps, making it suitable for high-speed applications.
• Low Standby Current: The TCA9509DGKR is designed for low standby current consumption, enhancing battery life in portable applications.
• Robust ESD Protection: It features 8-kV HBM (Human Body Model) ESD protection on all pins, providing a high level of protection against electrostatic discharge events.

Applications

The TCA9509DGKR is ideal for a wide range of applications, including:

• Level shifting for I²C-bus/SMBus signals in multi-voltage systems.
• Interface between applications with different voltage requirements.
• Extension of I²C-bus communication distances.
• Use in consumer electronics, mobile devices, and communication infrastructure.

Package and Quality

Encased in an MSOP (Mini Small Outline Package) with 8 pins, the TCA9509DGKR is designed for surface mount technology, allowing for efficient assembly and space-saving on PCBs. Texas Instruments ensures high-quality standards, with each device being rigorously tested to meet industry specifications for performance and reliability.
