The SN75LVDS84ADGGR is a FlatLink™ receiver integrated circuit designed and manufactured by Texas Instruments. This high-performance product is part of TI's interface family, specifically tailored for the transmission of high-speed data under demanding electrical conditions.

Key Features

• Interface Type: LVDS (Low Voltage Differential Signaling)
• Data Rate: Supports pixel clocks up to 112 MHz
• Channels: 28 bits (21 data, 7 control) through a 56-bit LVDS interface
• Package: TSSOP (Thin Shrink Small Outline Package) with 56 pins
• Operating Temperature: -40°C to +85°C, suitable for industrial applications
• Power Supply: 3.3V single supply operation
• Compatibility: Conforms to the TIA/EIA-644 LVDS Standard

Applications

The SN75LVDS84ADGGR is primarily used in applications that require high-speed data transmission with minimal signal degradation over long distances or through noisy environments. It is ideal for:

• Laptop and notebook computers
• Flat panel displays and projectors
• Industrial control and automation systems
• Digital copiers and printers
• Telecommunications equipment

Performance Benefits

This product offers several benefits for systems requiring reliable high-speed data transfer:

• Reduced Electromagnetic Interference (EMI): The LVDS technology minimizes EMI, which is crucial for maintaining signal integrity in sensitive applications.
• Low Power Consumption: Designed for efficiency, it consumes less power, making it suitable for portable and battery-operated devices.
• High Data Rates: The ability to support high pixel clocks makes it suitable for high-resolution video and graphic applications.

Quality and Reliability

Texas Instruments is known for its commitment to quality and reliability, and the SN75LVDS84ADGGR is no exception. It is designed to meet the rigorous standards required by industrial and commercial applications, ensuring long-term performance and stability.
