SN74LVC2G17DCK3 - Texas Instruments

The SN74LVC2G17DCK3 is a high-performance, dual Schmitt-trigger buffer designed by Texas Instruments to provide optimal solutions for a wide range of digital signal conditioning tasks. This integrated circuit belongs to the 74LVC family, which is renowned for its low-voltage operation and low power consumption, making it an excellent choice for modern electronic applications where power efficiency is crucial.

Key Features

• Operating Voltage: The device operates over a wide voltage range of 1.65 V to 5.5 V, making it compatible with various logic levels and suitable for interfacing with both 3.3 V and 5 V systems.
• Dual Schmitt-trigger Inputs: Schmitt-trigger action at all inputs makes the circuit tolerant to slower input rise and fall times, which is beneficial for applications that are susceptible to noise or have long rise and fall times.
• High Drive: It can drive up to 24 mA at the output, allowing for direct driving of LEDs or other high-current devices.
• Low Power Consumption: This device is designed for low power consumption, with a typical ICC of only 10 µA maximum.
• ESD Protection: The inputs and outputs are designed to withstand electrostatic discharge (ESD) events, with protection exceeding JESD 22, ensuring robust performance in harsh environments.
• Compact Packaging: The SN74LVC2G17DCK3 comes in an SC70-6 package, which is a very small and thin package, ideal for space-constrained applications.

Applications

The SN74LVC2G17DCK3 is versatile and can be used in a multitude of applications, including:

• Signal conditioning and buffering
• Line receivers with noise filtering
• Reset or interrupt signaling
• Level translation from 3.3V to 5V systems
• Wave shaping of clock or data signals

With its robust design and high functionality, the SN74LVC2G17DCK3 from Texas Instruments is an essential component for designers looking to enhance signal integrity in their digital systems while maintaining low power consumption and high integration.
