The SN74LVC1G17DCKRE4 by Texas Instruments is a high-performance, single-line Schmitt-trigger buffer designed to ensure a high degree of signal integrity in a variety of digital applications. This component is part of the LVC (Low-Voltage CMOS) family, which is well-known for its low-power consumption and high-speed operation.

Key Features

• Operating Voltage: The device operates over a broad voltage range of 1.65V to 5.5V, making it suitable for interfacing with both 3.3V and 5V logic levels.
• High Drive: It is capable of driving up to 24mA at the output, allowing it to drive multiple loads or to be used in bus-termination applications.
• Low Power Consumption: The SN74LVC1G17DCKRE4 is designed for low dynamic power consumption, with a typical ICC of only 10 µA (max).
• Schmitt-Trigger Action: With Schmitt-trigger action, the inputs have hysteresis which enhances noise immunity and allows the device to be used in slower input rise and fall time applications.
• ESD Protection: It features robust electrostatic discharge (ESD) protection, ensuring a high level of reliability and longevity in harsh environments.
• Small Footprint: The device comes in a compact SC70 (SOT-323) package, making it an excellent choice for space-constrained applications.

Applications

The SN74LVC1G17DCKRE4 is versatile and can be used in a wide range of applications, including but not limited to:

• Signal conditioning for noisy environments
• Line drivers with high noise immunity
• Wave shaping and timing circuits
• Glitch-free power-up/power-down circuits
• Interface translation when migrating from 5V to 3.3V logic without needing two supply voltages

Quality and Reliability

Texas Instruments is known for its commitment to quality, and the SN74LVC1G17DCKRE4 is no exception. It is designed and manufactured to meet the highest quality and reliability standards, ensuring stable performance across its operational lifespan. Whether used in commercial, industrial, or even more demanding automotive environments, this buffer provides the performance and reliability expected from a leading semiconductor manufacturer.
